AGG e10F new Hardware

Security
Reimagined.

SecureGate integrates elite network performance with AI-powered threat protection. Engineered for mission-critical infrastructure.

120G

IPsec Tput

5M+

Connections

0.9μs

Latency

SECUREGATE
ASIC Accelerated
Console
Gigabit Ethernet
PWR
STA
ALM
HW_REV: 100F-GEN3 // TRUSTED PLATFORM
800-4521-X9A

Built on the metal.
Powered by Linux.

We stripped away the bloat. Our custom networking stack utilizes DPDK and eBPF to deliver line-rate performance even with full threat inspection enabled.

Single-Pass Architecture

Parallel processing of signatures. Content is scanned once for IPS, AV, and App Control, reducing latency to microseconds.

TechnologyO(1) Lookup

eBPF Kernel Offload

Zero-copy packet processing directly in the Linux kernel. Bypassing the TCP/IP stack for trusted flows.

TechnologyXDP / eBPF

TLS 1.3 Inspection

Hardware-accelerated SSL/TLS decryption. Visibility into encrypted traffic without the performance penalty.

TechnologyAES-NI

Threat Intelligence

Real-time signature updates streamed from AGG Cloud Labs. Blocking 0-day exploits before they execute.

TechnologyLive Feed

Granular App Control

Layer 7 visibility. Identify and control over 4,000+ applications regardless of port, protocol, or encryption.

TechnologyDPI Engine

SD-WAN Integrated

Application-aware routing. Dynamic path selection based on jitter, packet loss, and latency metrics.

TechnologyOverlay
DevSecOps Ready

Configuration as Code.
No GUI required.

Forget clicking through endless wizards. Manage your entire fleet using our REST API, Terraform provider, or the native structured CLI.

JSON-RPC API

Full programmatic access to the control plane.

GitOps Workflow

Version control your security policies. Rollback in seconds.

admin@agg-gateway:~
# Configure high-performance interface
$agg-cli interface set --id eth0 --mode dpdk --mtu 9000
# Apply firewall policy (Layer 7)
$agg-cli policy add --name "block-mining" \
$ --src any --dst any \
$ --app "crypto-mining" --action drop
# Verify engine status
$agg-cli engine status --full
[SUCCESS] Interface eth0 bound to DPDK driver (vfio-pci)
[SUCCESS] Policy "block-mining" applied (Rule ID: 1024)
[INFO] Engine running: 128 threads, 0 dropped packets
$
https://gateway.local/dashboard

Security Fabric

System Status: Optimal

Live Throughput24.5 Gbps
Threats
IPS Attacks142
Malware89
Botnet12
Resources
12%CPU
48%RAM
Policy "Web-Filter" updated
Visual Analytics

Single Pane of
Glass Control.

Prefer a graphical interface? Our FortiView-inspired dashboard gives you real-time visibility into network traffic, threats, and user behavior.

  • Drill-Down Analytics

    Click on any chart to filter logs instantly. Identify bandwidth hogs and compromised hosts in seconds.

  • Unified Policy Management

    Manage Firewall, SD-WAN, and ZTNA rules from a single, intuitive table view.

  • Report Generation

    Automated PDF compliance reports (PCI, HIPAA) delivered to your inbox.

HARDWARE ACCELERATION

Unfair Advantage.

Stop processing packets in software. Our custom NPU (Network Processing Unit) offloads encryption and inspection, delivering up to 10x performance per watt compared to generic x86 CPUs.

Firewall Throughput

Raw UDP throughput (1518 byte packets)

Unit

Gbps

AGG e10F (ASIC)120 Gbps
Vendor P (x86)45 Gbps
Vendor C (x86)38 Gbps
* BASED ON DATASHEET RFC 2544 BENCHMARKLATENCY: <2μs
Price / Gbps$4.20Industry Avg: $18.50
Max Sessions8MConcurrent TCP
Power Draw35WMax Load
Form FactorDesktopFanless Design
Flexible Deployment

One OS.
Any Architecture.

// Deploy as a physical appliance, virtual machine (KVM/ESXi), or cloud instance. Same CLI, same policies.

WAN / ISP

Secure Edge Gateway

Replace legacy routers

Unified threat management at the ISP handoff. Full BGP/OSPF routing stack with ECMP support.

BGPOSPFSD-WAN
VLAN 10
VLAN 20

Internal Segmentation

Zero Trust Architecture

Micro-segmentation for east-west traffic. Isolate infected hosts instantly without disrupting the core.

VXLANVLANACL

Hybrid Cloud Ramp

Secure Site-to-Cloud

High-speed encrypted tunnels to AWS/Azure/GCP. Hardware offloaded IPsec for minimal latency.

IPsecWireGuardGeneve
Linux FoundationDPDK ProjectWireGuardCNCF
Technical Datasheet

Hardware Specifications

Model: AGG-e10F-G3 (Rev 3.0)

Hardware

Processor
Quad-Core ARM Cortex-A72 (1.8GHz)
Memory (RAM)
4GB DDR4 ECC
Local Storage
64GB eMMC (System) + 256GB NVMe (Logs)
Security Chip
TPM 2.0 Module Integrated

Interfaces

1GbE RJ45
8x (Switchable LAN/WAN)
10GbE SFP+
2x (High-Speed Uplink)
Console
1x RJ45 Serial (Cisco Style)
USB
1x USB 3.0 (Recovery / 4G Modem)

Environment

Power Input
100-240V AC (External Brick) or 12V DC
Max Power Consumption
25W (Average: 18W)
Operating Temp
0°C to 40°C (Fanless Passive Cooling)
Dimensions
215 x 150 x 35 mm (Desktop / Wall-mount)

Reliability

MTBF
> 120,000 Hours @ 25°C
Certifications
CE, FCC Class B, RCM, VCCI, CB, UL
Compliance
NDAA Compliant, TAA Compliant
Warranty
Lifetime Hardware Warranty (with Sub)
Enterprise ReadyFully compliant for government and critical infrastructure deployments.
NDAA Compliant
TAA Compliant
ISO 27001
GDPR Ready
